Movable Pipe Rack: If you're racking pipe on wood, a Movable Pipe rack is available. Cleats on the bottom of the pad bite into the wood to prevent movement. As the rack fills with drill pipe, two men can relocate the pad as needed.

Derrick Area & Steps: This high-traction work surface is custom molded 3⁄4” thick for use on stairways, derrick boards, and workover rigs.

Product: Sis molded from a high strength, fire retardant and chemical resistant urethane. Safety Pad III FR is now offered in a high or low profile version for applications not requiring the stainless steel studs or grooves. This high- traction work surface is custom molded 1 1⁄4” thick for the high profile version to fit the rotary table, drill floor, and any other critical work or walk area. Using the same urethane and maintaining the high standards as industry leading Safety Pad II FR, Safety Pad III FR offers a traction pattern that is molded into the surface of the mat. Because of the new design, we are able to offer this low-cost alternative.

Features:

• High Profile: standard thickness including the base and the highest point on the knobs is 1 1⁄4"
• Low Profile: standard thickness including the base and the highest point on the knobs is 1"
• Non-skid Coating

Benefits:

• Prevents Slip & Fall Injuries
• Increases Workplace Comfort & Well-Being
• Easily Integrated for Portable & Permanent Installations
• Reduces Costs

Product: The CS-150 Pipe Rack Mat has long been proven to improve the efficiency of tripping pipe by reducing potential lost time and eliminating unnecessary risks.

CS-150 is a 100% solid urethane elastomer and is made of a higher density polymer than our standard traction pads. This custom formulation offers extreme hydrolytic stability, anti-fungal properties and ultraviolet stability. Fluid channels are molded directly into the design in one direction facilitating drainage and providing extra traction. These pads are built to withstand the compression and weight of drill pipes. CS-150 resists the effects of invert and other corrosive drilling fluids.

With directional drilling becoming a prominent and important part in almost all drilling operations, efficiency needs to be a part of every operators play book. The historic method of racking pipe in birdbaths and on gator racks slows operations down when multiple pipe strings are in use.

By using the CS-150 Pipe Rack Mat, operations can be carried out more smoothly and eliminate the need to position pipe more cautiously on the pegs that are designed and spaced for only one size of pipe. A perfect example of how this will improve operations is when a rig hand misses a racking peg - the operation becomes disrupted by them having (in most cases) to pick the pipe back up and re-positioning it, ultimately adding trip time. Not only does this add time, it increases the potential for an accident by disrupting the flow and potentially creating pinch hazards.

Features:

• Standard thickness is 1 1⁄2"
• Non-skid Coating
• Hazard Identification
• Anti-fungal & UV Protective Properties
• Fluid Channels

Benefits:

• Prevents Slip & Fall Injuries
• Easily Integrated for Portable & Permanent Installations
• Reduces Costs

Product: Our Safety Pad AF anti-fatigue pads are some of the best things you can spend your money on. They improve ergonomics, body mechanics and enhance the workplace. It is similar to eye glasses in the way that they give you an immediate performance boost while improving your vision. Our anti-fatigue mats instantaneously make tasks more comfortable and efficient, thereby improving productivity.

Standing still is harder on your body than almost anything else. The body is designed to move and be dynamic, not to be static with your body mass load pressing down on your joints and crushing your blood vessels flat. This causes a lot of strain and fatigue on the body and creates pressure points which are really uncomfortable.

As with all of our pads we've continued to manufacture this version using the same highly regarded polymer blends that outperform & outlast our leading competitors. Safety Pad AF is also available in the Arctic version.

Safety Pad AF comes standard with a low traction profile but can be manufactured with stainless steel studs upon request.

Features:

• Standard thickness is 1"
• Non-skid Coating
• Hazard Identification
• Anti-fungal & UV Protective Properties
• Arctic version available

Benefits:

• Prevents Slip & Fall Injuries
• Increases Workplace Comfort & Well-Being
• Environmentally Pro-active
• Anti-fatigue Properties - Reducing Chronic Bodily Injuries
• Easily Integrated for Portable & Permanent Installations
• Reduces Costs

Product: This all-season traction pad provides the combined benefits and comforts of self-regulating radiant heat within the legendary Safety Pad II FR or the new Safety Pad III FR.

Specifically designed for use within the drilling industry with its rugged and durable properties, this traction pad is also ideal for use within any highly demanding industry sector such as gas plants, refineries, manufacturing facilities, mining operations and other industrial plants when the toughest mat is needed.

Built within this highly regarded and proven polymer compound, this heated and innovative industrial traction pad prevents and reduces ice and/or snow accumulation throughout your operations, thereby eliminating preventable hazards while increasing productivity.

This all-season option of traction pad is simple to install and uses any available power supply. While drawing a minimal amount of power depending on the environment and ambient temperatures, our heated traction pad system is ideal for all hazardous and/or high traffic situations and is the first of its kind that is suitable for Class 1 Div 2 locations.

The Arctic Pad family of mats offers the option of either stainless steel studs for extreme traction, or choose our stud-less version using our newest non-studded pattern.

System Technical Information: The Arctic Pad uses any available power supply and draws approximately 20 watts per square foot. The active current draw is subject to the ambient conditions surrounding the system as well as the specific model chosen. Common supply voltages: 110-120vac or 208-277vac on request. Moisture, chemical, and fire retardant.

Features:

• Heated
• Non-skid Coating
• Hazard Identification
• Anti-fungal & UV Protective Properties
• Minimal Power Consumption
• Chemical & Corrosion Resistance
• Familiar Groove/Stud Pattern
• Fire Retardant

Benefits:

• Prevents Slip & Fall Injuries
• Prevents Ice & Snow Accumulation
• Increases Workplace Comfort & Well-Being
• Environmentally Pro-active
• Easily Integrated for Portable & Permanent Installations
• Reduces Costs

Product: Slightly less chemical resistant than Safety Pad II FR and Safety Pad III FR, TC-90 Traction Mats are great for preventing employees, clients and customers from slip/fall type accidents.

This urethane elastomer blend combines high strength and elongation with excellent chemical resistance.
We offer a 1” thick version as a cost-effective option for the areas surrounding the rotary table.

Stainless steel studs and drainage grooves are molded into the surface to assist in the control of fluids that can accumulate during drilling operations. A non-skid coating seals the mats, while providing additional traction and durability. It creates a barrier of protection from chemicals, diesel, other corrosive fluids and ultra-violet rays.

Features:

• Standard thickness is 1” for areas surrounding rotary table
• Stress & Impact Resistant
• Flexible, Durable Design
• Highly Durable, Chemical &Corrosive Resistant

Benefits:

• Customizable to any shape/size
• Easily Installed
• Improves Workplace Safety
• Long Lasting

Product: We custom mold every order to your specifications and measurements. Therefore we need your exact dimensions. For simple shapes (like for a pipe rack) simply email or fax us a sketch with dimensions.

Dimensions and openings on rotary tables vary greatly from manufacturer to manufacturer. To assist you in measuring, we have provided drawings to guide you on our website.

Click on the type of rotary- A new window will open displaying the rotary as well as the standard measurements for each size of that rotary. If your rotary is not a standard size, print out the drawing and fill in all necessary dimensions. Once completed, email us the drawing and we will work up a price quote for you. If you have any questions, please give us a call at 281-482-8668, and we would be happy to help you.
Is your rotary table raised or flush?
